Plastic Plate Die

Once processors have experience with our carbide coatings to protect Plastic Plate Die from abrasion and corrosion, they often ask if we can coat other wear items in their process. This has resulted in our Cushion Master carbide protecting non-return valves, Ultrasonic Welding Horns, ejector pins, mold surfaces, polymer gear pumps, pneumatic conveying tubing, etc. We have developed solutions for all of these items, some very successful and some less so. We are open to helping find solutions to whatever issue you may have.

We Plastic Plate Die for a number of processors that extrude PVC through pipe and sheet dies. As PVC degrades, hydrochloric acid can result which corrodes steel and removes chrome plating.

In coat-hanger or siding dies, PVC degrades and builds up at the outward flow path of the die. This leads to frequent disassembly and cleaning, which shortens die life and results in the need for more frequent refurbishment.

We are working to help solve this corrosion problem with thermal spray coating. Our finished layer has very low porosity, which results in very high corrosion resistance. This polished surface resists material build-up and the hard particles will not scratch with aggressive hand cleaning.

The goal of this project is to at least double the time between complete refurbishment of dies and to reduce the need for frequent disassembly for cleaning.

Plastic Plate Die Application:transport,decorate,advertisement,chemical,exhibition,package

Item Specification
Die steel P20/5CrNiMo
Material PE/HDPE/LDPE/PA/PS/LDPP/HDPP/ABS/EVA/PC/PMMA
Width of the die 500mm-5000mm
Thickness of the product 2-20mm
Choked flow rope 90°
Way of flow passage clothes rack type
voltage 220V/50hz
Heating type heating inside
Heater element stainless steel heating rod
Mode of connection closed cycled connection
Fastening piece 12.9 high strength
Precision of polishing Polishing precision of the stream surface of the die lip 0.03-0.04(μm)other parts is 0.04-0.05(μm)
Galvanization  the stream surface of the die head are treated by chrome treatment. Thickness 0.03-0.04(μm),hardness: 60-65Rockwellc,the chrome treatment thickness of the ektexine is 0.01-0.02mm.
Installation according costumer’s request
Way of charging central ring charging way
