T-die for Aluminium-Plastic Sheet

Applications:electronic accessories,chemical,energe,car,machinery

Parameters of the T - die for Aluminium - Plastic Sheet

Item Specification Diesteel :P20/5CrNiMo

Material PE/PP Width of the die :500mm-5000mm

adjustable Thickness of the product :2-9m

T - die for Aluminium - Plastic Sheet Applications:electronic accessories,chemical,energe,car,machinery

Item Specification
Die steel P20/5CrNiMo
Material PE/PP
Width of the die 500mm-5000mm adjustable
Thickness of the product 2-9mm
Choked flow rope 45 °
Way of flow passage clothes rack type
Voltage 220V/50hz
Heating type heating inside
Heater element stainless steel heating rod
Mode of connection closed cycled connection
Fastening piece 12.9 high strength
Precision of polishing Polishing precision of the stream surface of the die lip 0.03-0.04(μm)other parts is 0.04-0.05(μm)
Galvanization  the stream surface of the die head are treated by chrome treatment. Thickness 0.03-0.04(μm),hardness: 60-65Rockwellc,the chrome treatment thickness of the ektexine is 0.01-0.02mm.
Installation according costumer’s request
Way of charging central ring charging way
